Image name
|
OCEANX9909280347
|
| Platform/Sensor |
Ocean-7/RAR |
| Flight altitude/speed |
650 km / 6.9 km/s |
| Image partition |
No; visual image is supplied in the same picture
|
| Wavelength(s)/Frequency(ies)/Band(s) |
0.0316 / 9.5 / X |
| Polarization(s) |
VV |
| Incidence angle(s) |
21°-46° |
| Calibration |
Black is lowest value of radar signal, white is highest value of radar signal.
Calibration steps. |
| Date/Time |
28.09.99 / 03:47-03:50 |
| Area |
Southern Okhotsk Sea, Pacific Ocean, south of Kuril Islands, Urup |
| Coordinates |
48°N, 148°E; 48.5°N, 153°E;
38.5°N, 150.5°E; 39.0°N, 155.0°E |
| Surface geometry |
460km * 1100km |
| Other signatures seen in the image |
Atmospheric internal waves |
