Experiment: DYMIO
OMNIDIRECTIONAL IONOSPHERIC MASS SPECTROMETER
Main scientific objectives:Investigation of the dynamics of the Martian Ionosphere and of its interaction with the Solar Wind.
DYMIO allows to measure:
main parameters of the ionospheric plasma: ion densities, temperatures and velocities.
angular and energy spectrum of superthermal ions up to 500 eV in the boundary layer between the ionosphere and the Solar Wind.
detailed mass composition of the ionospheric plasma up to mass 44 amu.
| Main characteristics:
| |
| |
| Field of View | 4x3,14 |
| Sensitivity | better than 0.1 ion/cm3 |
| Time resolution | 0.5 s |
| Mass range | 1-44 a.m.u. |
| Number density range | from less than 10-1 to 105 ions/cm3, accuracy 10% |
| Temperature range | from 500° K to 10 000° K, accuracy 10% |
| Velocity range | from 0.1 to 4 km/s, accuracy 10% |
| Data flow | 1 to 2 kb/s |
| Mass [kg] | 7,2 |
Cooperation:France, Russia, Germany, USA.
| Contact persons: | J.Berthelier (PI) Jean-Jocques.Berthelier@cetp.ipse.fr
O.Vaisberg olegv@iki.rssi.ru
|
|
MARS-96
