(35a) Planetary Gravity-Assist and the Pelton Turbine

    The most significant words of discovery are not "Eureka, I found it" but "Hmmm. That is funny."                Anonymous

Lester Pelton

The way in which a spacecraft increases or decreases its kinetic energy by swinging around a moving planet is very similar to the way a certain type of water turbine, the Pelton Wheel, extracts energy from a fast jet of water.

Lester Pelton, the inventor of the device, was born in 1829 in Vermillion, Ohio, on the shores of Lake Erie. In 1850 he arrived in California with the gold rush migrants and became a fisherman on the Sacramento river. Around 1853 he gave up on fishing and started working in the gold mines of Camptonville, Nevada City and Grass Valley, on the Yuba river in the "mother lode country." In 1864 he became a carpenter and millwright.

By that time the search for gold had progressed from sifting creek gravel ("placer mining") to processing large amounts of ore--from gravel deposits on the surface and from hard-rock mining. This required power--to drive stamp mills that crushed the ore, to pump air into mine tunnels and later to provide electricity and compressed air. Some mines used steam engines, but these needed a large and constant supply of firewood.

Mountain creeks could also supply energy, but the amount of their water was rather limited, although it fell from great height. Therefore, instead of the slow (and inefficient) water wheels traditionally used by flour mills, which needed only a moderate height but used a large amount of water, mine owners installed turbines--wheels with cups around their circumference, on which a fast jet of water was directed, coming from a high-up reservoir.

    According to a 1939 article by W. F. Durand of Stanford University in Mechanical Engineering, Pelton´s invention started from an accidental observation, some time in the 1870s. Pelton was watching a spinning water turbine when the key holding its wheel onto its shaft slipped, causing it to become misaligned. Instead of the jet hitting the cups in their middle, the slippage made it hit near the edge (drawing); rather than the water flow being stopped, it was now deflected into a half-circle, coming out again with reversed direction. Surprisingly, the turbine now moved faster
                  Hmmm. That is funny.

    Planetary gravity-assist,
    once more

What is the connection with planetary gravity-assist maneuvers? Earlier it was shown that when a ping pong ball with velocity u = –20 mph (right-to-left, positive; left-to-right, negative) hit head-on a paddle going at v = +20 mph, it rebounded with a velocity
    vfinal = –u + 2v = +20 + 40 = 60 mph
It can be shown that the same formula always holds--that in any encounter where u and v are along the same line (in either direction),
    vfinal = –u + 2v
Consider now four situations:
  1. The ball moves left-to-right and the paddle moves in the opposite direction. Then (–u) and v are both positive, so the magnitude of vfinal is always larger than the initial velocity (–u). The final energy
    Efinal = (m/2) (vfinal)2
    is increased.

  2. The paddle does not move at all. Then v=0 and
    vfinal = –u
    The final velocity has the same magnitude as the initial one, only the direction is reversed. The energy is unchanged.

  3. Both ball and paddle move in the same direction, left-to-right, and the ball overtakes the paddle, then both u and v are negative. The final velocity
    vfinal = –u + 2v
    is the sum of a positive number (-u) and a negative one (2v). Its magnitude is therefore less than the magniitude (-u) of the initial velocity: the ball comes out moving more slowly than before. Its energy is reduced.

  4. In particular, if v = u/2, a negative number (e.g. v = –10 mph in the example given), then
    vfinal = 0
    and the ball just dribbles out with no velocity of its own.
Encounters between a moving planet and a spacecraft behave very much in the same way. Head-on encounters increase the energy and overtaking encounters decrease it. In encounters where both planet and spacecraft move along different directions, the energy can also increase or decrease, depending on conditions, and in addition the direction of motion changes.

Sometimes losing energy is just what is needed. Suppose a scientific probe is to be sent to the Sun. A spacecraft which has escaped the Earth´s gravity still circles the Sun at about 30 km/sec, and to escape the solar system it needs an added push of about 12 km/s. To reach the Sun is much harder: the spacecraft needs (at the very least) to lose all its orbital velocity, which requires a boost of 30 km/sec against the direction it is moving. Once all its velocity is lost, it falls freely sunward.

NASA´s Solar Probe, meant to approach the Sun within 4 solar radii (about 2% of the Sun-Earth distance), has similar requirements. As far as rocket power is concerned, the most economical way of achieving that mission (though not the fastest) may well be sending the spacecraft outwards towards Jupiter, 5 times more distant from the Sun. It would then make a tight loop around the planet, overtaking it in such a way that practically all its orbital velocity around the Sun is lost, and then fall towards the Sun.

The Operation of the Pelton Wheel

    The mechanical behavior of a spacecraft encountering a moving planet, along its line of motion, is very similar to that of a water jet hitting the edge of a hemispherical cup-vane in a turbine wheel, where its motion is turned around by 180° (drawing).

    If the vane does not move, the only effect is to reverse the jet´s direction. Apart from some energy lost to friction, the energy of the jet, and the magnitude of its velocity, stay the same as before.

As with the spacecraft, if the vane moves towards the jet, the water gains speed; if it overtakes a vane moving away, it loses speed.

 Action of the
 Pelton wheel
In particular, if the water overtakes a vane moving at half its speed, then (neglecting friction) it loses all its velocity and just dribbles out of the moving vane.

Now total energy is always conserved. Neglecting friction losses (which are converted to heat), the kinetic energy lost by the jet is converted to additional rotational energy of the turbine wheel, speeding up its motion, or perhaps helping run machinery connected to it. By adjusting the speed of the jet to be equal to twice the speed of the vanes, almost all of the jet´s energy can be converted into useful output.

    [A problem with the De-Laval turbine is that cannot easily attain this condition. Though the steam jet converts heat energy very efficiently, to efficiently extract energy from the jet, the turbine wheel should match half the jet's velocity. But the jet is supersonic: if it moves at (say) twice the speed of sound, the periphery of the wheel should be moving at the speed of sound, which is rather fast for a power turbine.

     Modern steam turbines use several sets of blades. The first set extracts only part of the energy, and the jet coming out of it is still quite fast. Since the jet now moves in the opposite direction, it must be reversed before it can give more energy to the second blade in line. That is done by a set of stationary blades, firmly attached to the housing of the turbine. As in case #2 above, such blades take away none of the energy.]

That was Pelton´s great discovery. In other turbines the jet hit the middle of the cup and the splash of the impacting water wasted energy. In technical terms, the impact there resembled an inelastic collision, whereas in the turbine which Pelton developed, the deflection of the jet resembled an elastic collision, like the encounter between a spacecraft and a moving planet.

Through the later 1870s Pelton developed his design, settling in the end on a double cup with a wedge-shaped divider in the middle, splitting the jet--half to the left, half to the right. (You can approximate that design by cupping your hands upwards, then bringing them together, with the fingernails of one hand touching the ones of the other.) In the winters of 1877 and 1878 he tested turbines of different sizes, including a small one for running his landlady´s sewing machine (it worked, but he was not happy with the design). In 1880 he also obtained a patent on his invention.

Pelton then tried to sell his turbines, but met with little success until the spring of 1883, when the Idaho Mining Company of Grass Valley in Yuba County, California, arranged a competition between different designs, before deciding which design it would buy. Pelton´s turbine won by reaching an efficiency of 90.2%, whereas the three competing water wheels only attained 76.5%, 69.6% and 60.5%. After that sales grew at a tremendous rate, and in 1888 Pelton with some partners formed in San Francisco the Pelton Water Wheel Company, which expanded production even more.

While Pelton´s turbines were installed all over the world, some of his best customers were right in the "mother lode country" where he began his career. The biggest Pelton wheel ever built measured 30´ across and is now on display in Grass Valley, while a 15-ton wheel, on view in nearby Nevada City (its image at the beginning of this section--the memorial plaque is portrayed above), provided 18000 horsepowers of electricity for nearly 60 years. Pelton ultimately moved to Oakland, on San Francisco Bay, and died there in 1908. He never married.
